4.18.6. Example 6: Establish and Verify Packet Forwarding in a Switch
Test Ports 1,1 and 1,2 need to be connected to a DUT that supports packet forwarding. Verify that both ports 1,1 and
1,2 are linked before performing the following tasks.
Hint: Pre-configure test ports for AUTO Address on All Ports – this will assure that packets originated in test port 1,1
are addressed to test port 1,2 and visa versa. Also, be sure to prime any switch bridging logic prior to forwarding
packets.
# Example 6 script
# Using PVA-3102 in slot,port 1,1 for Tx, 1,2 for Rx
# Configure MAC Addresses for transmission 1,1 to 1,2 and back
set TxPort 1,1
set RxPort 1,2
pva_pkt_addr $TxPort auto match store
# Configure both Test Ports for auto speed, duplex, polarity.
pva_speed $TxPort auto duplex auto arm
pva_polarity $TxPort auto arm
pva_speed $RxPort auto duplex auto arm
pva_polarity $RxPort auto arm
# Force a re-link, to establish the desired line conditions.
pva_relink $TxPort
pva_relink $RxPort
# Verify that the links are up.
pva_link_wait $TxPort
pva_link_wait $RxPort
# Transmit Traffic on both ports to prime any switch bridging
pva_tx_pkt $TxPort size 60 rate line count 0
pva_tx_pkt $RxPort size 60 rate line count 0
after 30000
pva_tx_pkt $TxPort stop
pva_tx_pkt $RxPort stop
# Start the Received Packet Counter on the RxPort.
set rslt [pva_rx_pkt $RxPort start]
# Transmit 512k packets with the TxPort
set rslt [pva_tx_pkt $TxPort size 60 rate line count 512K
start]
# Check for Transmit completed
while {[lindex [pva_tx_pkt $TxPort stat] 3] != "IDLE"} { }
# Read the Received Packet Counter.
set rslt [pva_rx_pkt $RxPort stat]
# Stop the Received Packet Counter.
pva_rx_pkt $RxPort stop
