Page #127 background imageLoading...
Page #127 background image
PVA-3000 Reference Manual
December 2, 2019 Sifos Technologies
Page
127
6.1.3. Multi-Port Packet Transmission and Analysis
When Packet Flow testing is utilized to test 10/100/1000BaseT receivers on and Ethernet switch, the process of
transmitting and receiving packets can be conducted simultaneously across multiple test ports. This feature allows
impaired receiver tests to be conducted essentially in parallel, thus reducing overall test time.
Multi-Port Packet Flow testing will typically include the following four steps:
1. Initiate Packet Counting on all Test Ports
20. Initiate Packet Transmission on all Test Ports
21. Monitor for Packet Transmission Complete on a Port-by-Port basis
22. Recover Packet Counts
In the following script example, packets are transmitted from Test Port 1 on slots 1-4 and captured on Test Port 2 of
those slots.
# Discontinue any prior packet transmission and counting
pva_rx_pkt 99,99 stop
pva_tx_pkt 99,99 stop
# Configure MAC addresses so Port 1 transmits to Port 2 on each slot and visa versa
pva_pkt_addr 99,99 auto match
# Establish Transmit and Receive Test Ports
set txPortList [list 1,1 2,1 3,1 4,1]
set rxPortList [list 1,2 2,2 3,2 4,2]
# Configure burst packet transmission to all Test Ports
pva_tx_pkt 99,99 size 128 rate line count 1024K
# Start all the Rx counters in parallel - we can ignore the ones
# that we don't care about when we retrieve the results.
pva_rx_pkt 99,99 start
# Start the Tx packet flow on the specific ports that we want transmitting
foreach port $txPortList {
pva_tx_pkt $port start
}
# Loop waiting for the burst packet transmissions to complete
# Remove ports from Tx Port List when measurements are completed
while { [llength $txPortList] > 0 } {
# Check each port's transmission status
foreach port $txPortList {
set status [lindex [pva_tx_pkt $txPort stat] 3]
# If burst transmission complete, remove Test Port from Tx List
if { $status == "IDLE"} {
set idx [lsearch $txPortList $port]
set txPortList [lreplace $txPortList $idx $idx]
}
} ; # Tx Port List
} ; # Scan Loop
# Wait DUT-specific time for all traffic to forward through all DUT ports
after 1000
# Retrieve all of the Rx counts to array variable rxCounts, discontinue packets
foreach port $rxPortList {
set status [pva_rx_pkt $port stat]
set rxCounts($port,Count) [lindex $rawStat 6]
set rxCounts($port,CRCErr) [lindex $rawStat 8]
}
pva_rx_pkt 99,99 stop
pva_tx_pkt 99,99 stop
