PVA-3000 Reference Manual
December 2, 2019 Sifos Technologies
The pva_caps test evaluates Link Stability at each supported connection polarity (MDI/MDI-X) for each advertised
link rate (10/100/1000), duplex mode (half, full), and 1000BaseT timing mode (master, slave). The table below
describes each of the reported parameters from the pva_caps test.
DUT does not support Auto-Negotiation
DUT supports Auto-Negotiation, but does not support Next Page Capability
DUT supports Auto-Negotiation, including Next Page Capability
Auto-Negotiation information not available
Link code word received, Next Page Acknowledge received
No acknowledgements received
DUT does not support 1000Base-T
DUT supports 1000Base-T Half Duplex only
DUT supports 1000Base-T Full Duplex only
DUT supports 1000Base-T Half Duplex and Full Duplex
DUT does not support 100Base-TX
DUT supports 100Base-TX Half Duplex only
DUT supports 100Base-TX Full Duplex only
DUT supports 100Base-TX Half Duplex and Full Duplex
DUT does not support 10Base-T
DUT supports 10Base-T Half Duplex only
DUT supports 10Base-T Full Duplex only
DUT supports 10Base-T Half Duplex and Full Duplex
DUT does not support 100Base-T4
DUT does support 100Base-T4
DUT does not support Pause operation
DUT capable of full duplex pause operation
DUT desires asymmetric pause
DUT desires asymmetric pause, capable of full duplex pause operation
DUT has detected remote fault
MASTER/SLAVE configuration fault detected
DUT supports both MDI and MDI-X
DUT is able to link to non-auto-negotiating (10Base-T, Half-Duplex) partner
DUT requires auto-negotiation in order to link
DUT Remote Receiver (1000Base-T) indicates Not OK
DUT Remote Receiver (1000Base-T) indicates OK
Could not be assessed – not applicable
DUT supports both MASTER and SLAVE configuration
DUT supports both MASTER configuration only
DUT supports both SLAVE configuration only
Could not be assessed – not applicable
Auto-Resolution of MASTER / SLAVE did not produce a Fault indication
Auto-Resolution of MASTER / SLAVE produced a Fault indication
Could not be assessed – not applicable
Forced MASTER timing (link partner = SLAVE) did not produce Fault indicator
Forced MASTER timing (link partner = SLAVE) produced a Fault indication
Could not be assessed – not applicable
Forced SLAVE timing (link partner = MASTER) did not produce Fault indicator
Forced SLAVE timing (link partner = MASTER) produced a Fault indication
Could not be assessed – not applicable
