Simrad GO XSE User Manual

4 Point data
5 Bottom
6 Depth history
Setting up the ForwardScan image
Depth
Controls depth range. Depth range is set to auto mode by default.
Forward range
Controls the forward looking search range. Maximum Forward
range is 91 meters (300 feet).
Noise Rejection
Filters out signal interference and reduces on-screen clutter.
Record
Records ForwardScan sonar logs.
Pause
Pauses forward-looking Echosounder transmissions.
ForwardScan view options
Palette
Several display palettes are available for a variety of water
conditions.
History ratio
Controls how much Echosounder history is shown behind the boat.
The higher the ratio, the more history will be shown.
Point data
By default, ForwardScan only shows the bottom. Select the Point
data menu option to specify to view no sonar data points, all sonar
data points, or only points (Objects) in the water column.
138
ForwardScan | GO XSE Operator Manual

Simrad GO XSE Specifications

General

GPS	Yes
Chartplotter	Yes
NMEA 2000	Yes
Wi-Fi	Yes
Bluetooth	Yes
Waterproof Rating	IPX7
Operating Voltage	12V DC
Sonar	Yes (built-in)
Cartography	C-MAP, Navionics
Mounting Type	Bracket or Flush Mount
Screen Size	7-inch, 9-inch
Screen Resolution	800 x 480 pixels
