Simrad GO XSE User Manual

Charts
The chart function displays your vessel’s position relative to land
and other chart objects. On the chart panel you can plan and
navigate routes, place waypoints, and display AIS targets.
The Chart panel
1 Waypoint*
2 Vessel with extension line (extension line is optional)
3 Route*
4 North indicator
5 Grid lines*
6 Range rings*
7 Track*
8 Chart range scale
9 Range rings interval (only displayed when Range rings are
turned on)
* Optional chart items. You turn the optional chart items on/off
individually from the Chart settings dialog.
4
Charts | GO XSE Operator Manual
33

Simrad GO XSE Specifications

General

GPS	Yes
Chartplotter	Yes
NMEA 2000	Yes
Wi-Fi	Yes
Bluetooth	Yes
Waterproof Rating	IPX7
Operating Voltage	12V DC
Sonar	Yes (built-in)
Cartography	C-MAP, Navionics
Mounting Type	Bracket or Flush Mount
Screen Size	7-inch, 9-inch
Screen Resolution	800 x 480 pixels
