Ú
Note: A heading sensor must be present in the system for radar
overlay.
When the radar overlay is selected, basic radar operational functions
are available from the Chart panel’s menu.
Selecting radar overlay source on chart panels
To select the radar source of the radar overlay displayed on the
chart panel, use the Radar options and then Source chart panel
menu options to select the radar source.
For chart pages with more than one chart with radar overlay, it is
possible to set up different radars sources for each chart panel.
Activate one of the chart panels and then select one of the available
radars in the radar source menu option. Repeat the process for the
second chart panel with radar overlay, and select an alternative
radar for this panel.
Radar operational modes
The radar’s operational modes are controlled from the Radar menu.
The following modes are available:
Power off
The power to the radar scanner is turned off. Power off is only
available when radar is in standby mode.
Standby
The power to the radar scanner is on, but the radar is not
transmitting.
Ú
Note: You can also put the radar in standby mode from the
System Controls dialog.
Halo light
Controls the levels of the Halo Radar pedestal blue accent lighting.
There are four levels possible for the lighting. The accent lighting
can only be adjusted when the radar is in standby mode.
Ú
Note: The blue accent pedestal lighting might not be approved
for use in your boating location. Check your local boating
regulations before turning the blue accent lights ON.
94
Radar | GO XSE Operator Manual
