Panning the 3D chart
You can move the chart in any direction by selecting the Pan icon
and then panning in the desired direction.
Select the Return to vessel menu option to stop panning, and to
center the chart to vessel position.
Controlling the view angle
You can control the view angle by selecting the Rotate icon and
then panning the chart panel.
• To change the direction you are viewing, pan horizontally
• To change the tilt angle of the view, pan vertically
Ú
Note: When centered on the vessel position, only the tilt angle
can be adjusted. The view direction is controlled by the chart
orientation setting. See "Positioning the vessel on the chart panel" on page
35.
Zooming a 3D chart
You zoom in and out on a 3D chart by using the zoom (+ or -)
buttons, or the touch method of pinching and spreading your
fingers.
Chart overlay
Structure, SonarChart Live (Navionics charts only) and weather data
can be displayed as overlay on your chart panel.
Ú
Note: Radar can also be displayed as overlay on chart panels on
units with radar. Radar functions are described in the chapter
"Radar" in this manual.
When an overlay is selected, the chart menu expands to include
basic menu functions for the selected overlay.
Information about the overlay data are described in more detail in
separate sections in this manual.
Insight and C-MAP charts
All possible menu options for Insight and C-MAP charts are
described below. The features and menu options available can vary
40
Charts | GO XSE Operator Manual

Simrad GO XSE Specifications

General

GPS	Yes
Chartplotter	Yes
NMEA 2000	Yes
Wi-Fi	Yes
Bluetooth	Yes
Waterproof Rating	IPX7
Operating Voltage	12V DC
Sonar	Yes (built-in)
Cartography	C-MAP, Navionics
Mounting Type	Bracket or Flush Mount
Screen Size	7-inch, 9-inch
Screen Resolution	800 x 480 pixels
