Sindoh C300 - 11.9 Adjusting scanner registration; 11.10 Adjusting ADF registration

12-52
Troubleshoot a problem
12
Action Yes No
Step 3
1)Turnofftheprinter,waitforabout10seconds,andthen
turn the printer on.
2)Copy or scan the document.
Is the scanner responding?
The problem is
solved.
Contact customer
support.
11.9 Adjusting scanner registration
1
From the control panel, navigate to:
Settings →Device→ Maintenance → Config Menu → Scanner Configuration → Scanner Manual Registration
2 Touch Print Quick Test.
3 Place the Print Quick Test page on the scanner glass, and then touch Flatbed Registration.
4 Touch Copy Quick Test.
5 Compare the Copy Quick Test page with the original document.
Note
- If the margins of the test page are different from the original document, then adjust Left Margin and Top Margin.
6 Repeat step 4 and step 5 until the margins of the Copy Quick Test page closely match the original document.
11.10 Adjusting ADF registration
1
From the control panel, navigate to:
Settings →Device→ Maintenance → Config Menu → Scanner Configuration → Scanner Manual Registration
2 Touch Print Quick Test.
3  PlacethePrintQuickTestpageontheADFtray.
4  TouchFrontADFRegistrationorRearADFRegistration.
Note
- ToalignFrontADFRegistration,placethetestpagefaceup,shortedgefirstintotheADF.
- ToalignRearADFRegistration,placethetestpagefacedown,shortedgefirstintotheADF.
5 Touch Copy Quick Test.
6 Compare the Copy Quick Test page with the original document.
Note
- If the margins of the test page are different from the original document, then adjust Horizontal Adjust and Top
Margin.
7 Repeat step 5 and step 6 until the margins of the Copy Quick Test page closely match the original document.
