SKF KFGL - Page 85

10. KFGL control unit
KFGL
Information mode
Step Key Display Description
1
Entry mask/language selection
The German version is active by default (flashing).
Press the “up” arrow key to change to the English version.
Press the ENTER key
2
Main menu
Press the ENTER key to go to the Info menu.
3
Info menu
You can switch between menu items using <arrow key up> and <arrow key down>.
Press the ENTER key to go to the selected menu.
Press the ENTER key
4
Serial number
Each control unit has an assigned serial number that can be viewed by pressing the ENTER key.
Firmware
This is the current version number of the software and can be viewed by pressing the ENTER key.
Sys time
This displays the total running time (on-time) of the control unit in hours, minutes, and seconds.
Mot time
This displays the total runtime of the pump motor in hours, minutes, and seconds.
Err time
This displays the total time of the current error (if present). If there is currently no error state, the display
shows the sum time of all errors detected thus far.
Press the <<arrow key left> to return to the main menu.
<Press <arrow key left>
Mot time
Err time
English
German
Info
Config
Status
Serial number
Firmware
Sys time
Sys time
ØØØØØh
ØØm ØØs
Mot time
ØØØØØh
ØØm ØØs
Err time
ØØØØØh
ØØm ØØs
Page 85
EN
