9.13.2 Insert
The panel can be inserted if necessary for resuscitation purposes.
5 Pull the headboard handrail evenly up-
wards. Avoid jamming it.
6 Pull the headboard panel upwards.
7 After removing the headboard panel, reinsert the handrail to provide stability. The locking
mechanism must audibly engage.
1 Proceed in reverse order to the removal process.
2 Press both release buttons on the headboard handrail at the same time and pull the handrail up
evenly to remove it.
3 Slide the panel into the grooves
in the headboard. Please note
that the projections at the side
of the panel must be at the top
of the panel.
Use/routine
91 Instruction Manual
