8.3 Insert/remove patient lifting pole
Mattress retainer bars are supplied as fixed-position or fold down bars, depending on the
features of the bed.
Only possible if this bed is equipped with the optional adapter sleeve for patient lifting
poles/infusion stands.
•
Always lay the mattress [1] on the mattress base between the four lateral mattress retain-
er bars [2] . This prevents the mattress from moving outwards at the sides of the bed.
•
Please also note any other possible position markings on the mattress (such as “Oben/
Top”; “Kopf/Head”).
•
Always place the mattress onto the mattress base in the way described below.
Top view (shown schematically): Mattress base with properly inserted mattress
Detail (shown schematically): CORRECT: Mat-
tress lies within the mattress retainer bars
Detail (shown schematically): INCORRECT:
Mattress lies outside/above the mattress retain-
er bars
Bed reprocessing/bed adaptation
55 Instruction Manual
