11.5 Adjusting the sitting position and the normal position
Only possible when equipped with a control box in the linen holder.
The mattress base height and tilting angle are saved.
For safety reasons, the only tilted position that can be saved is the reverse-Trendelen-
burg position.
The positions of the backrest and thigh rest are not saved and remain unchanged.
This description applies to both the sitting position button and the normal position
button
6 Press the UP button. 7 A display of OK ! and a beep acknowl-
edge that an intermediate stopping po-
sition has been successfully set. The
symbol for the intermediate stopping
position is then displayed again.
1 Set the desired new position for the bed
3X
or
Special bed adaptations
Instruction Manual 106
