6.5.5.5 Control box
Similar to illustration!
magnetic unlocking key is necessary to access the medical staff and technician control level
on the LCD handset. Changing between control levels on the LCD handset is done by hold-
ing the magnetic sensor on the LCD handset briefly (for about ½ second) against the mag-
netic unlocking key, see LCD handset (optional) » 24.
The control box is used to carry out all motorised adjustments and to lock handset functions
for the patient.
When the bed is connected to the mains supply, a yellow LED indicates that the battery is
charging.
The control box is located in the linen holder and can be attached to the footboard handrail.
Image5:
Position of control box
The buttons and LEDs on the control box have the following functions:
Product description
Instruction Manual 30
