Operation 5
Driving
1
360° steering (standard)
The steering wheel has no mechanical stops
and can be continuously turned.
Starting in the straight-ahea
d position, the
steered wheel reaches the 90° p
osition after
2, 2½ or 3 revolutions (can be co
nfigured) of
the steering wheel. This pos
ition corresponds
to the truck’s smallest turn
ing radius. The
steering can be turned furth
er from this
position (1), which reverse
s the drive direction.
The drive direction indicator on the display and
operating unit shows the actual drive direction.
1
180° steering (variant)
The steering wheel has no mechanical stops
and can be continuously turned.
The path of travel (1) is determined by turning
the steering wheel. The maximum steering
angle of the steered wheel is 90° to each
side. To reverse the drive direction, the drive
direction switch must be actuated.
The drive direction indicator on the display and
operating unit shows the actual drive direction.
50
988078001 [EN] 101
