5 Operation
Driving
Roadways
Dimensions of roadways and aisle widths
Within the EU, Directive 89/654/EEC (mini-
mum safety and health requirements for the
workplace) must be observed. The respective
national guidelines apply for areas outside
of the EU. In each case, it must be checked
whether a larger aisle width is necessary, e.g.
in the case of different load dimensions.
Thetruckmayonlybeusedon
roadways
that do not have excessivel
y sharp bends,
excessively steep gradien
ts or excessively
narrow or low entrances.
Driving on gradients
WARNING
Driving up and down longer gradients may result in
the drive unit overheating or the minimum specified
braking values being exceeded.
– Do not drive up or down longer gradients.
– Do not exceed the maximum permissible gra-
dients for roadways (see table below).
The truck is designed for normal operation
on smooth, even roadways without major
gradients, up to a maximum of 3%.
The following gradients (e.g. on ramps) must
not be exceeded when using the truck under
any circumstances:
Max. permissible gradient in
%
With load Without load
FM-X 10, FM-X 12, FM-X 14,
FM-X 17, FM-X 20, FM-X 25
15 20
FM-X 10N, FM-X 12N, FM-X
14N, FM-X 17N, FM-X 20N
15 20
Picking up a load, putting down a load, stack-
ing or unstacking is only permitted on a hori-
zontal, level surface.
Warning in the event that components
project beyond the truck contour
Trucks are often required to drive through very
narrow or very low spaces such as aisles or
containers. The dimensions of the trucks are
88
50988078001 [EN]
