5 Operation
Operating auxiliary equipment
Camera/monitor system (variant)
CAUTION
Risk of accident due to collision of the lift mast or
load with the racking or low ceilings.
– Also, when using the system, always consider
the vibration characteristics of the lift mast and
the load.
– Note that the camera image only shows a small
part of the surrounding area.
The camera/monitor system helps the driver
place loads into stock or remove loads from
stock at great lift heights. Using the cam-
era image, loads can be picked from and de-
posited at high levels without having to look
up, thus avoiding neck and shoulder strain.
– Refer to the manufacturer’s operating
instructions for information about operation
of the camera/monitor system.
Load measurement
NOTE
Calibration of the load measurement system
must be carried out by the authorised service
centre.
General
The "load measurement" variant helps the
driver by displaying the weight of the lifted load
on the display and operating unit.
The weight is measured by an additional
weight sensor at the valve block. The sensor
measures the weight with an accuracy of +/-
10% deviation.
The calculated data is also evaluated by
assistance systems such as OPTISPEED
and Active Load Stabilisation (ALS).
Requirements for load measurement
The load must be in the inactive position so
that the weight sensor provides accurate
results.
15
0 50988078001 [EN]
