Operation 5
Battery change frame (variant)
Battery replacement area
Requirements for the battery replace-
ment area
There must be sufficient space to allow the
change frames to be positioned and for the
truck to be driven through the area.
The battery replacement ar
ea must be hori-
zontal, level and have a suf
ficient load capac-
ity.
There must also be enough space to allow the
operator to move safely around the change
frames and to operate the change frames.
There must be sufficient room between
the truck and the surrounding building or
fixed installations so that the operator and
passers-by can safely move around the area.
This area must be at least 0.5 m wide.
Afirstaidkitsuitablefo
r accidents involving
acids must be available.
Persons trained in
first aid must be availab
le and within calling
distance.
Requirements for posi
tioning the change
frames
The transfer height of the frame and truck must
be aligned with one another; see the chapter
entitled "Battery change frame/Adjusting the
transfer height"
In order to move the battery in and out easily,
the roller channels must be set exactly hori-
zontal. Use a spirit level.
Wear of the truck whe
els will change the
transfer height. In
such instances, change
the height setting o
f the levelling feet.
When the truck and battery rack are positioned
relative to each other in accordance with the
specifications, the battery replacement can be
carried out.
50
