Still FM-X - VDI Datasheet FM-X 10 (N), FM-X 12 (N)

Technical data 7
VDI datasheet FM-X 10 (N), FM-X 12 (N
)*
VDI datasheet FM-X 10 (N),
FM-X 12 (N)*
*Subject to change
DS = drive side
LS = load side
All dimensions include sideshift/fork tilt; mast
sideshift not possible.
1) Decreases for larger batte
ries by 90 mm in each case depending on battery size
2)
Calculation in accordance with VDI 3597, extended for larger batteries by 90 mm in each
case depending on battery size
3) Dependent on the lift mast, sideshift/fork tilt: 2°/4°
Characteristics
FM-X 10 FM-X 10 N FM-X 12
FM-X 12
N
1.1 Manufacturer STILL STILL STILL STILL
1.2
Manufacturer’s type
designation
FM-X 10 FM-X 10 N FM-X 12
FM-X 12
N
1.3 Drive Electric Electric Electric Electric
1.4
Operation
Seated Seated Seated Seated
1.5
Load capacity/load
Q
kg
1000 1000 1200 1200
1.6
Load centre of g
ravity
cmm
600 600 600 600
1.8 Load distance
xmm
278 184 278 184
1.9 Wheelbase
y
mm
1275 1275 1275 1275
.
Weights
FM-X 10 FM-X 10 N FM-X 12
FM-X 12
N
2.1
Net weight (including
battery)
kg
3250
3220 3250 3220
2.3
Axle load without
front/rear load
kg
2130/1120 1980/1240 2130/1120 1980/1240
2.4
Axle load with fork
forwards with front/rear
load
kg
980/3540 920/3300 840/3610 780/3640
2.5
Axle load with fork
backwards with front/rear
load
kg
1880/2370 1600/2620 1830/2620 1520/2900
.
50
988078001 [EN] 253
