1 Foreword
Information about the documentati
on
Schematic views
View of functions and operating proce-
dures
At many points in this documentation, the
(mostly sequential) operation of certain func-
tions or operating procedures is explained. To
illustrate these operations, schematic views of
a reach truck are used.
NOTE
These schematic views are not representative
of the structural state of the documented truck.
The views are used solely for the purpose of
clarifying procedures.
View of the display and operating unit
NOTE
Views of operating statuses and values in the
display of the display and operating unit are
examples and partly dependent on the truck
equipment. As a result, the displays shown of
the actual operating statuses and values may
vary.
