Still FM-X - VDI Datasheet FM-X 20 (N, W, EW)

Technical data 7
VDI datasheet FM-X 20 (N, W, EW)*
VDI datasheet FM-X 20 (N, W,
EW)*
*Subject to change
DS = drive side
LS = load side
All dimensions include sideshift/fork tilt; mast
sideshift not possible.
1) Decreases for larger batte
ries by 90 mm in each case depending on battery size
2)
Calculation in accordance with VDI 3597, extended for larger batteries by 90 mm in each
case depending on battery size
3) Dependent on the lift mast, sideshift/fork tilt: 2°/4°
Characteristics
FM-X 20 FM-X 20 N
FM-X 20
W
FM-X 20
EW
1.1 Manufacturer STILL STILL STILL STILL
1.2
Manufacturer’s type
designation
FM-X 20 FM-X 20 N
FM-X 20
W
FM-X 20
EW
1.3 Drive Electric Electric Electric Electric
1.4
Operation
Seated Seated Seated Seated
1.5
Load capacity/load
Q
kg
2000 2000 2000 2000
1.6
Load centre of g
ravity
cmm
600 600 600 600
1.8 Load distance
xmm
410 307 400 400
1.9 Wheelbase
y
mm
1525 1525 1525 1525
.
Weights
FM-X 20 FM-X 20 N
FM-X 20
W
FM-X 20
EW
2.1
Net weight (including
battery)
kg
3810 3780
2.3
Axle load without
front/rear load
kg
2470/1340 2440/1340
2.4
Axle load with fork
forwards with front/rear
load
kg
820/4990 860/4920
2.5
Axle load with fork
backwards with front/rear
load
kg
2170/3640 2030/3750
.
