7 Technical data
VDI datasheet FM-X 20 (N, W, EW)*
Wheels, chassis frame
FM-X 20 FM-X 20 N
FM-X 20
W
FM-X 20
EW
3.1
Tyres Polyureth. Polyureth. Polyureth. Polyureth.
3.2
Front tyre size
mm
Ø 360 x 130
Ø 360 x
130
Ø360x
130
Ø 360 x
130
3.3
Rear tyre size
mm
Ø 350 x 100
Ø 350 x
100
Ø350x
100
Ø 350 x
100
3.5
Number of wheels at
front/rear (× = driven)
1x/2 1x/2 1x/2 1x/2
3.7 Rear track width
b11
mm
1167 1037 1367 1567
.
Basic dimensions
FM-X 20 FM-X 20 N
FM-X 20
W
FM-X 20
EW
4.1
Lift mast/fork carriage tilt,
forwards/backwards
a/b
(°)
°
1/3 2/4
1/3 1/3
4.2
Height with lift mast
retracted h1
mm
2450 2450 2450 2450
4.3
Free lift
h2
mm
1880 1880 1880 1880
4.4
Lift
h3
mm
5580 5580 5580 5580
4.5
Height with lift mast
extended h4
mm
6150 6150 6150 6150
4.7
Height of overhead
guard (cab)
h6
mm
2270 2270 2270 2270
4.8
Seat height
h7
mm
1140 1140 1140 1140
4.10
Height of load wheel
supports
h8
mm
373 373 373 373
4.19
Tota
l length
l1
mm
2484 2589 2484 2484
4.20
Length including fork
back
l2
mm
1334 1439 1334 1334
4.21 Total width
b1/b2
mm
1270 1140 1470 1670
4.22 Fork arm dimensions s/
e/l
mm
50 / 100 /
1150
50 / 100 /
1150
50 / 100 /
1150
50 / 100 /
1150
4.23
ISO 2328 fork carriage,
class/model A, B
2/A 2/A 2/A 2/A
4.24
Fork carriage width
b3
mm
760 760 760 760
4.25
Width across forks,
min./max.
b5
mm
316/620 316/620 316/620 316/620
4.26
Width between load
wheel supports
b4
mm
920 790 1120 1320
4.28
Reach forward
l4
mm
623 520 608 608
