Still FM-X - VDI Datasheet FM-X 22

7 Technical data
VDI datasheet FM-X 22*
Electric motor
FM-X 20 FM-X 20 N
FM-X 20
W
FM-X 20
EW
6.1
Traction motor, power
rating, S2=60 min.
kW
6.5 6.5 6.5 6.5
6.2
Lift motor, power rating,
S3=15%
kW
14 14 14 14
6.3
Battery in accordance
with DIN 43531/35/36 A,
B, C, no
43531C /
254-2
43531B /
254-2
43531C /
254-2
43531C /
254-2
6.4
Battery voltage/nominal
capacity K5
V/Ah
48/560 48/560 48/560 48/560
6.5
Battery weight (+/-5%
depending on the
manufacturer)
kg
940 940 940 940
6.6
Energy consumption in
accordance with VDI
cycle
kWh/h
6.7
Handling performance
t/h
6.8
Energy consumption
at max. handling
performance
kWh
in
1h
(kWh/h)
.
Other
FM-X 20 FM-X 20 N
FM-X 20
W
FM-X 20
EW
10.1
Working pressure for
attachment
bar 254 254 254 254
10.2 Oil flow for attachments
l/min
20 20 20 20
10.7
Sound pressure level in
driver’s compartment
dB(A)
69 69 69 69
Distributed load in
accordance with VDI
2199
kg/m2
2744 2910
.
VDI datasheet FM-X 22*
*Subject to change
DS = drive side
LS = load side
