5 Operation
Lift height preselector (variant)
This can only be done using the service
software.
The following parameters, among others, can
be changed using the service software:
• Pallet free lift height
• Pallet free lowering height
• Accuracy and speed of pallet free lift and
pallet free lowering
• Accuracy and speed of homing
Performing a teach-in
The teach-in for height preselection is carried
out using the display and the enter keys for the
display and operating unit.
The values for the progra
mmable lift heights
must be entered via the en
ter keys on the
numeric keypad. It is not
possible to move the
fork to a lift height and t
ransfer this value to the
height preselection sys
tem.
Opening the lift heigh
t preselector menu
12
34
– For information on the general operation of
the truck configuration, as well as entering
a password with a specific authorisation
16
6 50988078001 [EN]
