Defining directions
56
8
7
1
3
4
2
General:
• left (1)
•right(2)
Drive directions:
• Travelling in the load direction (backwards)
(3)
• Travelling in t
he drive direction (forwards)
(4)
Movements of th
e reach carriage:
• Extending the reach carriage (in the load
direction) (5)
• Retracting the reach carriage (in the drive
direction) (6)
Tilting the lift mast or fork:
• Backward tilt
(7)
•Forwardtilt(8)
Thedriversitscrosswisetothedrivedirection.
