5 Operation
Working with attachments
The LED (4) indicating the clamp locking
mechanism has been unlocked lights up and
the clamp can now be opened. If the clamp
locking mechanism is locked again, the LED
will go out.
– To open the clamp, press and hold shift
button "F" and move the operating lever
forwards again.
NOTE
The clamp locking mechanism is locked again:
• as soon as shift button "F" is released
• if the clamp is not opened w
ithin a specified
period of time
Pickingupaloadusinga
ttachments
WARNING
Risk of accident!
Attachments must only be used for their intended
purpose as described in the relevant operating
instructions.
Drivers must be taught how to operate the attach-
ments.
WARNING
Risk of accident!
Loads may only be picked up and transported
with attachments if they are securely grasped
and attached. Where necessary, loads must also
be secured against slipping, rolling, falling over,
swinging or tipping over. Note that any change to
the position of the load centre of gravity will affect
the stability of the truck.
Check the capacityrating plates for the attachments
or combination of attachments.
– The rating plates show the permissible
values for:
• Load capacity Q (kg) (1)
• Lift height h (mm) (2)
• Load distance C (mm) (3)
14
6 50988078001 [EN]
