Technical data 7
VDI datasheet FM-X 20 (N, W, EW)*
FM-X 20 FM-X 20 N
FM-X 20
W
FM-X 20
EW
4.31
Ground clearance with
load under lift mast m1
mm
70 70 70 70
4.32
Ground clearance at
centre of wheelbase
m2
mm
70 70 70 70
4.34.1
Working width when
handling pallets
measuring 1000x1200
across forks
Ast
mm
2819 2879 2852 2892
4.34.2
Working width when
handling pallets
800x1200 lengthways
on forks
Ast
mm
2863 2940 2896 2936
4.35
Turning radius
Wa
mm
1778 1762 1810 1850
4.37
Length across the load
wheel supports
l7
mm
1922
1924
1922 1922
4.43
Step height
mm
345 345 345 345
.
Performance data
FM-X 20 FM-X 20 N
FM-X 20
W
FM-X 20
EW
5.1
Driving speed
with/without load
km/h
14/14 14/14 14/14 14/14
5.11
Driving speed
with/without load when
reversing
km/h
14/14 14/14 14/14 14/14
5.2
Lifting speed
with/without load
m/s
0.37/0.58 0.37/0.58 0.37/0.58 0.37/0.58
5.3
Lowering speed
with/without load
m/s
0.53/0.5 0.53/0.5 0.53/0.5 0.53/0.5
5.4
Reach speed
with/without load
m/s
0.18 0.18 0.18 0.18
5.7
Climbing capability
with/without load
%
10/15 10/15 10/15 10/15
5.8
Max. climbing capability
with/without load
%
15/20 15/20 15/20 15/20
5.9
Acceleration time (over
10 metres) with/without
load
s
5.10 Service brake
Gen./hydr.
mech.
Gen./hydr.
mech.
Gen./hydr.
mech.
Gen./hydr.
mech.
.
50
