Still FM-X - VDI datasheet FM-X 22*

7 Technical data
VDI datasheet FM-X 10 (N), FM-X 12 (N
)*
Wheels, chassis frame
FM-X 10 FM-X 10 N FM-X 12
FM-X 12
N
3.1
Tyres Polyureth. Polyureth. Polyureth. Polyureth.
3.2
Front tyre size
mm
Ø 360 x 130
Ø 360 x
130
Ø360x
130
Ø 360 x
130
3.3
Rear tyre size
mm
Ø 285 x 100
Ø 285 x
100
Ø285x
100
Ø 285 x
100
3.5
Number of wheels at
front/rear (× = driven)
1x/2 1x/2 1x/2 1x/2
3.7 Rear track width
b11
mm
1167 1037 1167 1037
.
Basic dimensions
FM-X 10 FM-X 10 N FM-X 12
FM-X 12
N
4.1
Lift mast/fork carriage tilt,
forwards/backwards
a/b
(°)
°
1/3 2/4 1/3 2/4
4.2
Height with lift mast
retracted h1
mm
2450 2450 2450 2450
4.3
Free lift
h2
mm
1890 1890 1890 1890
4.4
Lift
h3
mm
5750 5750 5750 5750
4.5
Height with lift mast
extended h4
mm
6310 6310 6310 6310
4.7
Height of overhead
guard (cab)
h6
mm
2270 2270 2270 2270
4.8
Seat height
h7
mm
1140 1140 1140 1140
4.10
Height of load wheel
supports
h8
mm
308 308 308 308
4.19
Tota
l length
l1
mm
2366 2462 2366 2462
4.20
Length including fork
back
l2
mm
1216 1312 1216 1312
4.21 Total width
b1/b2
mm
1270 1140 1270 1140
4.22 Fork arm dimensions s/
e/l
mm
40 / 80 /
1150
40 / 80 /
1150
40 / 100 /
1150
40 / 100 /
1150
4.23
ISO 2328 fork carriage,
class/model A, B
2/A 2/A 2/A 2/A
4.24
Fork carriage width
b3
mm
760 760 760 760
4.25
Width across forks,
min./max.
b5
mm
296/600 296/600 316/620 316/620
4.26
Width between load
wheel supports
b4
mm
920 790 920 790
4.28
Reach forward
l4
mm
449 364 449 364
25
4 50988078001 [EN]
