5 Operation
Handling loads
WARNING
The figures show examples.
Only the capacity rating plates on the truck are valid!
The attachment of additional weights to
increase load capacity is prohibited.
DANGER
Risk to life from the truck losing stability!
Never exceed the maximum loads shown! These
values apply to compact and homogeneous loads.
Otherwise, the stability as well as the rigidity of the
fork arms and lift mast cannot be guaranteed.
Improper or incorrect operation or the placement of
persons to increase load capacity is prohibited.
Example
Weight of load to be lifted (1)
Permissible lift height (2)
Load distance from fork back (3)
WARNING
Risk of accident from the truck losing stability!
The permissible loading of the attachments (va-
riant) and the reduced load capacity of the combi-
nation of truck and attachment must not be excee-
ded.
– Observe the special capacity rating plate infor-
12
