7 Technical data
VDI datasheet FM-X 25*
Wheels, chassis frame
FM-X 25
3.1
Tyres Polyureth.
3.2
Front tyre size
mm
Ø 360 x 140
3.3
Rear tyre size
mm
Ø 350 x 100
3.5
Number of wheels at front/
rear (× = driven)
1x/2
3.7 Rear track width
b11
mm
1167
.
Basic dimensions
FM-X 25
4.1
Lift mast/fork carriage tilt, forwards/back-
wards
a/b (°)
°
1/3
4.2
Height with lift mast retracted
h1
mm
2450
4.3
Free lift
h2
mm
1828
4.4
Lift
h3
mm
5580
4.5
Height with lift mast extended
h4
mm
6202
4.7
Height of overhead guard (cab)
h6
mm
2270
4.8
Seat height
h7
mm
1140
4.10
Height of load wheel supports
h8
mm
373
4.19
Total length
l1
mm
2556
4.20
Length including fork back
l2
mm
1406
4.21 Total width
b1/b2
mm
1270
4.22 Fork arm dimensions s/e/l
mm
50 / 120 / 1150
4.23
ISO 2328 fork carriage, class/model A, B
2/A
4.24
Fork carriage width
b3
mm
760
4.25
Width acr
oss forks, min./max.
b5
mm
336/640
4.26
Width between load wheel supports
b4
mm
920
4.28
Reach forward
l4
mm
695
4.31
Ground clearance with load under lift mast
m1
mm
70
4.32
Ground clearance at centre of wheelbase
m2
mm
70
4.34.1
Working width when handling pallets
measuring 1000x1200 across forks
Ast
mm
2908
4.34.2
Working width when handling pallets
800x1200 lengthways on forks
Ast
mm
2937
27
