Installing the Y Bellows
1. Transfer the Y bellows retainers to the new Y bellows.
2. Move the X bridge to the front of the gantry enclosure.
3. Install the front and rear clips (8) that secure the front Y bellows assembly to the X bridge and
oven frame. See Figure 7-33.
4. Install the rear clips (4) that secure the back Y bellows assembly to the rear of the oven frame.
See Figure 7-33.
5. Using a 3 mm hex wrench, install the screws (3) that secure the back bellows retainer to the back
of the X bridge assembly tray. See Figure 7-33.
