3 SYSTEM COMPONENTS
This chapter describes the components of the F123 Series. Information regarding the materials and tips that
can be used by the printer is also included in this chapter.
PRINTER OVERVIEW
ACCESS DOORS AND PANELS
This printer has been designed to allow easy access to the most frequently accessed areas on the system.
Doors and panels are highlighted in Figure 3-1 and Figure 3-2.
Figure 3-1: Access Doors and Panels - Front View
Warning: Do not energize when the rear panel is not secured in place.
Top Cover
Material
Bay
Drawer
Oven Door
Interface Panel
Front Side Panel
(left & right)
Storage
Drawer
Rear Side Panel
(left & right)
