Stratasys Objet24 - Opening Objet Tray Files

DOC-34014 Rev. C 5–13
Objet24 User Guide
Opening Objet
Tray Files
Youcanopentraysthatweresavedasobjtffiles.Thisisuseful,forexample,
ifyousavedatrayafterpreparingitforprinting,andnowyouwantto
makechangesbeforeprintingit.
To place an object saved as an Objet Tray File (objtf) file on the build
tray:
1. FromtheFilegroup,click .
or—
FromtheObjetStudioCommandsmenu ,select
Open.
TheOpendialogboxisdisplayed.
Figure 5-13: Objet Tray File Open dialog box
2. Selectthedesiredfile,andmakesurethatitappearsintheFilename
field.
IfthePreviewcheckboxisselected,theobjectisdisplayed.
3. Click
Open.
ObjetStudioopensthetrayfile.
The objtf file is actually a file containing instructions for printing—which stl
files to print and their position on the build tray. Because the objtf file
references the stl files used, they must remain in the same file location as
when the objtf file was saved.
