Screen Layout
ObjetStudioautomaticallyadjuststhedefaultscreenlayouttodisplaythe
optimumviewsofthebuildtrayandthemodeltree.Youcanviewmodels
fromdifferentperspectivesbychangingthescreenlayout.
To change the screen layout:
¾
OntheViewflyouttoolbar,selectSingle View,or4 Views.
Figure 5-38: Screen layout icons
 Single View isthedefaultscreenlayout.
 4 Viewsdisplaysperspective,top,frontandrightviews.
Figure 5-39: Single-view screen layout
Figure 5-40: 4-view screen layout
