Using Objet Studio
5–36 DOC-34014 Rev. C
Object display
options
Thedisplayformataffectshowquicklyobjectsdisplay.Forexample,ifyou
select
Bounding Box,objectsdisplayfasterthantheydowhenyouselect
Entire Object.Youcanchoosedisplayformatsforobjectswhentheyare
stationary(staticview)andforwhenyouaredraggingthem(changingview).
To select the object display preference while changing view, and in static
view:
1. Selecttodisplayobjects:
• WithaBoundingBox(seefigure 5‐21onpage 33)
• WithAdaptivePolygonReduction(changingviewonly)
• WithPolygonReduction(staticviewonly)
• EntireObject
2. Click
OKwhendone.
Zoom Options
Whilemanipulatingobjects,youoftenneedtoviewthematdifferentzoom
levels.
To change the zoom level:
¾
Ontheribbon,opentheZoomflyouttoolbarandselectanoption:
Figure 5-49: Zoom flyout toolbar
 ZoomObjectfocusesontheselectedobject.
 ZoomTraydisplaysthewholetray.
 ZoombyRectangleallowsyoutodisplayasectionofthetrayby
selectingitwiththemouse.
Youcanalsozoominandzoomoutwiththemousewheel.
Zoom Object
Zoom Tray
Zoom by Rectangle
You can configure Objet Studio to automatically zoom in on the objects
placed on the build tray. See “Automatic Zoom” on page 52.
