SummaCut cutter User’s Manual
Setup 1-23

Changing origin.
1.
Press , , and to change the origin.
The media will move to the new origin. Values will appear on the LCD. The X value
is the distance from the original origin; the Y value is the maximum cutting width.
2.
Press to toggle the Y value between the maximum cutting width and distance
from the original origin. Press to toggle between the maximum cutting length
and the distance from the original origin.
The X and/or Y value will toggle.
3.
Press if the desired origin is reached.
The cutter comes online and is ready to receive data from the computer.
4.
Or press to cancel.
The cutter will move to its original origin and come online.

Extended load.
The function extended load makes it possible to define the limits of the Y axis so that
the cutter can cut outside the pinch rollers. Media needs to be loaded before this
function can be used.
1.
Press .
The tool pressure will appear on screen.
2.
Press .
‘System Setup’ will appear on the LCD.
3.
Press .
‘’Actions’ will appear on the LCD.
4.
Press .
‘OPOS Barcode’ will appear on the LCD.
5.
Press or until ‘Extended Load’ appears on screen and press .
‘Origin’ will appear on the LCD.
6.
Press or to define the new limit at the right (origin).
The head will move to its new origin.
