Summa D120 - Loading the Graphic into the Cutter; Registering the Marks

SummaCut cutter User’s Manual
Contour Cutting 3-6
3.3.2
Loading the graphic into the cutter
Load the printout into the cutter as described in section 1.6. Make sure the mark,
indicating the origin, is situated at the bottom right corner of the cutter.
3.3.3
Registering the marks
The OPOS parameters are variables that define the distance, size, and number of
marks. These parameters are needed so the cutter can align the cut lines to the printed
job. Most cutting software sets these parameters automatically and even starts the
special load procedure.
If the software does not do this, initiate the loading sequence from the cutter’s touch
panel:
1.
Power on the cutter and load the media.
2.
Press .
‘Knife pressure’ will appear on screen.
3.
Press .
‘System Setup’ will appear on the LCD.
4.
Press .
‘’Actions’ will appear on the LCD.
5.
Press .
‘OPOS Barcode’ will appear on the LCD.
6.
Press and press .
‘’Media Alignment’ will appear on the LCD.
7.
Press .
A message prompting the user to set the knife above the first mark will scroll across
the LCD.
8.
Use , , and to do so and press .
The cutter will reload the media, check if the loaded length and read the marks.
NOTE: If a mark cannot be read, the user will be given the option to re-
position the knife (sensor) or to abort.
NOTE: If an error occurs or the cutter cannot read the marks after three
attempts, the following message will be displayed: “Mark
s could not be
sensed, press to continue.”
