Summa D120 - Setting Tool Parameters

SummaCut cutter User’s Manual
Basic Operation 2-3
How to Set Tool Parameters
2.2
The SummaCut cutters can work with a knife, pen or pouncing tool (optional).
Once a tool has been changed, the tool parameters must be reset or checked.
All the different tools have one parameter name in common: the pressure.
Each tool has also its specific parameters.
Tool parameters can be changed by either changing them in the current user, or simply
by changing the user (see section 0).
ATTENTION: The SummaCut cutters will only perform according to specifi-
cations if a genuine Summa knife, pen or pouncing tool is installed. Do not
replace the standard knife, pen or pouncing tool with products from other
manufacturers.
WARNING: Each keystroke can initiate an internal test or movement of the
head or media.
Keep fingers and other body parts away from the cutting
area. There are hazardous moving parts.
2.2.1
Setting the tool type
1.
Power on the cutter.
2.
Press .
‘Knife pressure’ will appear on the LCD.
3.
Use or to scroll through the menu until ‘Tool’ is reached. Press .
Current selected tool will appear on screen.
4.
Press or to change the tool.
The tool will change on the LCD.
5.
Press to confirm.
An asterisk will appear before the tool, indicating it is now the selected tool.
6.
Press twice to leave the menu.
If the tool type was changed, then the cutter will prompt the user to install the new
tool.
