SummaCut cutter User’s Manual
Detailed Operation 4-2
4.2.1
Pressure
Pressure is preceded by its tool name. This parameter is explained in section 2.2.2.
4.2.2
Knife offset
This parameter is explained in section 2.2.3
4.2.3
Pouncing Gap
The pouncing gap submenu is used to set or modify the distance between the
pounced holes. The default pouncing gap value is 1 mm.
After pressing the key, press the or jogging key until the desired
pouncing gap is displayed on the LCD and press to confirm.
The value can be set between 1 mm and 50 mm.
4.2.4
User
The SummaCut cutters include 4 user configurations, all of which consist of the same
parameters. Each configuration can have unique parameter settings. This allows the
cutter to be quickly and easily reconfigured for different types of jobs or media. This
parameter is explained in section 2.4.
4.2.5
FlexCut
The RESET instruction performs a complete reset of the cutter. Press the key to
execute a reset.
4.2.6
Tool
Different tools can be used on the SummaCut. A knife, a pen (without or with
penholder) and a pouncing tool. If a tool is changed, then use this menu to set the
machine to use this tool. This is explained in section 2.2.1.
4.2.7
System Setup
Press to access the rest of the parameters and internal tests. This menu is split up
into 4 submenu’s. Scroll through those submenu’s by using or .
