Summa D120 - RS-232 Connection

SummaCut cutter User’s Manual
Setup 1-17
1.5.3
RS-232 Connection
The RS-232 cable should be 5 meters (16 feet) or less in length. The connectors on
both sides are DB-9S type connectors. There is no need to install a device driver when
connecting a cutter with an RS-232 connection.
The parameters of the RS-232 connection must be set in either the properties of the
COM port in the device manager or in the cutting software program itself. Please refer
to the manual for the cutting software on how to set the parameters for the RS-232
connection with the cutter.
Default settings of the RS-232 connection are listed in the table below.
Baud rate
9600
Data Bits
8
Parity
none
Stop Bits
2
Flow Control
Hardware or XON / XOFF
TABLE 1-1
1-1 DEFAULT RS-232 SETTINGS OF THE SUMMACUT CUTTER
