Summa D120 - OPOS and Media Calibration

SummaCut cutter User’s Manual
Contour Cutting 3-2
3.2.1
OPOS calibration
1.
Switch the cutter on and load black vinyl with white backing.
ATTENTION: Black vinyl with white backing MUST be used when calibrating
OPOS. The media calibration setting must be set to the default value.
2.
Set the head’s origin above a clean, blank part of the vinyl.
3.
Press .
‘Knife pressure’ will appear on the LCD.
4.
Press .
‘System Setup’ will appear on the LCD.
5.
Press .
‘Actions’ will appear on the LCD.
6.
Use or to scroll through the menu until ‘Calibrations’ is reached, press
.
‘Cal. Media’ will appear on the LCD.
7.
Use or to scroll through the menu until ‘Cal. OPOS’ is reached, press .
The cutter will cut out a square measuring approximately 9.5x9.5 mm and move the
square forward. “Weed Rectangle” will appear on the display.
8.
Carefully weed the square, making sure the edges stay intact. Press .
OPOS will read the edges of the square and calibrate itself accordingly.
NOTE: In order to keep the accuracy of the OPOS sensor as high as
possible, do this calibration each time the knife is been replaced.
