SummaCut cutter User’s Manual
Basic Operation 2-2
2.1.1
Control Panel
2.1.1.1
The menu key
The
MENU
key is used to reach the most common menu items of the cutter quickly. A
last menu item in the row gives access to a submenu, which gives access to all the
other functions of the cutter (see section
2.3).
2.1.1.2
The exit key
The
EXIT
key (cancel key) cancels the current operation.
NOTE:
Pressing this key when the cutter is cutting stops the current job.
2.1.1.3
The enter key
The
ENTER
Key (confirm key) confirms a selected menu or a changed menu item.
As long as this key is not pressed, a changed value of a menu item will not be saved
internally and will be lost if the menu is left.
2.1.1.4
The test key
If there is a certain test routine in a submenu, this can be activated to start the test. This
key also starts the barcode procedure.
2.1.1.5
The jogging keys , , and
The use of the jogging keys varies according to the operation in progress.
For example, when working with different submenus, the or jogging key is
used to select the next or previous submenu.
When in a submenu, the values can be changed by pressing or .
When the cutter is in standard operation, the origin can be changed by pressing either
one of the jogging keys.
