SummaCut cutter User’s Manual
Contour Cutting 3-10
3.4.1
The parameter OPOS origin is created to automate the start of the OPOS procedure.
This parameter has 4 settings. The usage of this parameter depends on the chosen
OPOS mode.
This parameter can be found in the system sub menu OPOS parameters (see section
0).
If the OPOS is OPOS barcode or OPOS Sheet, then this parameter has no effect.
The useful combinations are mentioned in the table below.
In combination with OPOS X mode
OPOS Origin is set to ‘Mark’.
This is the default setting. Upon receiving an OPOS job from the computer, the cutter
will prompt the user to set the tool above the first mark and press Apply. The cutter will
then start searching for the OPOS mark around that position.
OPOS Origin is set to ‘Current position’.
Upon receiving an OPOS job from the computer, the cutter will immediately start
looking for the mark when it gets an OPOS job from the computer, without waiting for
the user to move the tool. Therefore, the user will have to set the tool above the first
mark while loading the material.
If OPOS origin is set to either ‘XY-correction line’ or ‘Centre of media’, the cutter will
react as if the parameter was set to ‘indicate mark’.
In combination with OPOS XY mode
OPOS Origin is set to ‘Mark’.
This is the default setting. Upon receiving an OPOS job from the computer, the cutter
will prompt the user to set the tool above the first mark and press Apply. The cutter will
then start searching for the OPOS mark around that position.
OPOS origin is set to ‘Indicate line’
Upon receiving an OPOS job from the computer, the cutter will prompt the user to set
the tool under the OPOS XY line and press Apply. The cutter will then start searching
for the OPOS XY line by slowly moving forward the media. Once it has found it, it will
follow this line to the right until it finds the location of the first mark and then it will start
searching for the actual first mark.
