SummaCut cutter User’s Manual
Press to confirm.
The value of the chosen parameter will appear on the LCD.
Press or to change the value to ‘ON’.
‘ON’ will appear on the LCD.
Press to confirm.
An asterisk will appear before ON, indicating it is now the selected setting.
Press twice to leave the menu.
Register the marks and cut the first contour as described in sections 3.3.4 and 3.3.5.
The cutter will stop after the first contour has been cut and will come online again.
Raise the pinch rollers and manually remove the sheet.
Insert the next sheet into the cutter. Lower the pinch rollers.
ATTENTION: The second and any following sheet must be loaded in the
cutter at the same position as the first sheet, with the same orientation. When
in OPOS sheet mode, the cutter stores the distance between edges of the
sheet and the first OPOS mark.
NOTE: Use easy orientation points to be able to quickly position the sheet. In
the figure below, a rim of the
base plate and the side of the pinch roller
assembly are used to align the sheets.
FIG 3-1
3-1 POSITION MEDIA FROM MULTIPLE SHEET
