SummaCut cutter User’s Manual
WARNING: Do not place any objects in front of, or behind, the cutter that
could interfere with cutter operation. Make sure the media is free to move
forward and back. Keep hands, hair, clothing and jewelry away from moving
While the cutter is activated, it will automatically start executing a minimal loading
procedure as soon as the pinch rollers are lowered. The load procedure will also start
when the cutter is switched on while media is already in the machine and the pinch
rollers are in the “down” position (this is not recommended). Always keep the pinch
rollers in the up position while the cutter is not being used.
The minimal loading procedure consists of:
A media width measurement.
Media is unwound over a length equal to the width measured between the
outer two pinch rollers.
A simultaneous 45° axial move of the drive drum (sleeves) and cutting head.
After that, the cutter is ready to receive files from the computer.
When receiving a job from the computer, the cutter will automatically pull the required
media from the roll. It does this in steps and the length of the vinyl used is equal to a
number of times the measured width of the media.
This load procedure is sufficient in most of the cases. However, there are some extra
load features available.
ATTENTION: Tracking of longer signs can only be guaranteed when the full
load procedure is performed!
WARNING: Each keystroke can initiate an internal test or movement of the
head or media. Keep fingers and other body parts away from the cutting
area. There are hazardous moving parts.
