SummaCut cutter User’s Manual
Setup 1-27

Setting knife depth and pressure:
(Media must be loaded in the cutter before the knife pressure can be tested).
WARNING: Each keystroke can initiate an internal test or movement of the
head or media.
Keep fingers and other body parts away from the cutting
area. There are hazardous moving parts.
1.
Press .
Knife Pressure will appear on the LCD.
2.
Press .
Current knife pressure will appear on the LCD.
3.
Press or to change the knife pressure.
The value will change
1. Press to perform the internal knife pressure test.
2. Press to confirm the chosen knife pressure.
3. Press to leave the pressure unchanged.
Once is pressed, the current knife pressure value will be automatically set to
the new value and the cutter will cut the knife pressure test pattern.
FIG 1-26
1-26 KNIFE PRESSURE TEST PATTERN
Peel out the rectangle and inspect the media backing.
The knife depth is set correctly when the test pattern cuts completely through the vinyl,
the vinyl is removed and the blade tip visibly scratched the front side of the media
backing. The blade should never cut through the backing; just slightly scratch the
silicon coating and first few fibres of the backing material.
Because the knife pressure setting depends on the thickness and type of media to be
cut, adjusting the knife pressure will require some practice. In general, the knife depth
must be increased when using thicker types of vinyl and decreased when using thinner
types of vinyl.
