Summa D120 - Control Panel and LCD

Basic Operation 2-1
2
Basic Operation
LCD and control panel
2.1
The liquid crystal display (LCD) contains one line of 16 characters. The LCD provides
cutter status information during operations and displays menu options for the
configuration of the cutter.
FIG 2-1
2-1 CONTROL PANEL
The liquid crystal display (LCD) contains one line of 16 characters. The LCD provides
cutter status information during operations and displays menu options for the
configuration of the cutter.
The various menu and submenu items are always presented in a loop, which means
that, when the last menu or submenu item is displayed, pressing the appropriate key
will automatically take you back to the first item of the same menu or submenu.
NOTE: A parameter or parameter value, preceded by an asterisk (*), is the
current selected parameter or parameter value. If a menu is left with a value
on the LCD, which is not preceded by an asterisk, then this will not be the
saved value.
WARNING: Each keystroke can initiate an internal test or movement of the
head or media.
Keep fingers and other body parts away from the cutting
area. There are hazardous moving parts.
