SummaCut cutter User’s Manual
Press .
The cutter will lower the sensor. On the display, the message ”put the sensor on
the white area” will appear.
Use , , and to manoeuvre the knife on top of a white area (the
area should be at least 3 by 3 cm or 1” by 1”).
Press to confirm.
The cutter will make a circular movement while it measures the reflection of the
media. It will briefly display the measured values and display the message “put
sensor on black area.”
Use , , and to manoeuvre the knife on top of a black area
(approximately in the middle and slightly to the bottom right).
Press to confirm.
The cutter will make a circular movement while it measures the reflection of the
mark colour. It will briefly display the measured values and will then show a value
that is characteristic for this media colour – mark colour combination. Store this
value for future reference.
ATTENTION: An error message may appear if the sensor is not able to
differentiate between black and white. Make sure the test has been
performed correctly. If OPOS is not able to sense the mark
s, one of the
manual alignment methods (see 0.) must be used.
