S CLASS™ cutter User’s Manual
Setup 1-33
Loading a sheet.
1. Press .
The actions menu will appear on screen..
2. Press .
A message will appear letting the user choose between roll and sheet.
3. Press
.
The cutter will immediately start to load the sheet. It measures the width and loads a certain
length of media, or until the end of the media is encountered. The user will then be prompted
to accept the length or not.
4. Press to accept the length or go to step 5.
The cutter will now complete the loading sequence and then come online and will be ready
to receive data. The loading sequence conditions the edges of the vinyl for a given length.
5. Press .
Two arrows will appear on the touch screen.
6. Press or until the required media length appears, then press .
The cutter will now complete the loading sequence. After that, the cutter will come online
and will be ready. The length of the job it can cut is limited to the loaded length.
NOTE: If the rear media sensor detects the end of the media, then the cutter will complete
the loading sequence without any input from the user.
