S CLASS™ cutter User’s Manual
Setup 1-34
Loading a roll.
1. Press .
The actions menu will appear on screen.
2. Press .
A message will appear letting the user choose between roll and sheet.
3. Press .
Four arrows will appear, together with an “apply” button. The status is visible in the middle
of the right-hand side of the screen.
4. Use , , or to reposition the origin, if necessary. Then
press .
Two arrows will stay on the screen with which the necessary length can be loaded.
5. The media length needed for the task can be entered by pressing or
and thus then loading the needed length. Or the needed length for the job can be
entered by pressing and then by pressing or to change the
value of the default length to load.
Depending on the manner chosen for entering the needed length of the job, the cutter will
either load the length or display the chosen length on screen.
6. Press
The cutter will now complete the loading sequence. Then the cutter will come online and will
be ready. The length of the job it can cut is limited to the actual length of the media that is
left on the roll. The cutter will always assume a full roll, thus it will use 50000mm (1982
inches) on the status screen.
When the built-in media sensors detect the end of the roll, the cutter will complete the
loading sequence and display the media size on the status window.
