S CLASS™ cutter User’s Manual
Contour Cutting 3-19
15. Check if the result is the satisfactory. If not change one of the 4 parameters above.
Reducing the velocity can also improve the result. It is never recommended to use
cutting speeds larger then 400mm/s (16 ips) with cutting pressures above 170 gr.
Note: It is not always easy to find the correct balance between cutting deep enough
making sure the pieces can be taken out easily, and not cutting too deep making sure
the material keeps it strength while cutting. Sometimes this balance doesn’t exist
meaning that this material can’t be cut through with satisfactory result.
Note: FlexCut parameters are always metric, regardless the value of the panel Units
parameter (see section on Panel Units:)
Note: When cutting through, it is recommended that parallel lines are at least 1 cm
away from each other. Otherwise, while cutting the second line, the first line may come
loose and cause trouble.
16. After that press .
The advanced cutting menu will appear on screen.
17. Press .
The paneling menu will appear on screen.
18. Press .
Current panel size will appear on screen.
19. Use
or to set paneling size, recommended values are 3 to 10cm.
New value will change.
20. Press to confirm.
The paneling menu will appear on screen.
21. Press .
The menu to disable or enable paneling will appear on screen.
22. Use or if necessary to enable paneling.
23. Press to confirm.
The paneling menu will appear on screen.
24. Press .
